Compact Case
// Guanghsing
// GHB-063
// -
Sales only to business customers.
Delivery time: upon request
Basic Module: Guanghsing GHB-063
| General information | ||||
| SKU / Item Number | GHB-063 | |||
| Product Basic Data | ||||
| Manufacturer | Guanghsing | |||
| Externe I/O (Front Panel) | ||||
| USB | USB 2.0 | 2 Pce | ||
| Inserts | ||||
| Internal | 3.5" Drive Bay | 1 Pce | ||
| external | 5.25" Drive Bay | 3 Pce | ||
| Cooling | ||||
| Implementation | Active (fan cooling) | |||
| Active | Fan | Quantity | 1 Pce | |
| Diameter | 90 mm | |||
| Air flow (at 100%) | 52 cfm | |||
| Motherboards | ||||
| Supported motherboards | ATX | |||
| Mechanical / Environment | ||||
| Relative humidity | Operation | 5 to 95%, non-condensing | ||
| Dimensions | Width | 330 mm | ||
| Deep | 440 mm | |||
| Height | 175 mm | |||
| Weight | 10100 g | |||
| Controls | Power | 1 Pce | ||
| Reset | 1 Pce | |||
| Status indicators | Storage | 1 Pce | ||
| Power | 1 Pce | |||
| Slots and Brackets | Standard | 7 Pce | ||
| Color | Black | |||
| Material | Steel | |||
| Mounting option | Wall Mount | |||
| Certificates / Conformities | ||||
| CE | Yes | |||
| FCC | Class A | Yes | ||
| RoHS compliant | Yes | |||
