Fortron Source FSP200-PNA

FSP200-PNA-A12, FSP200-PNA-A24, FSP200-PNA-A48

Open-Frame Power Supplies

PRODUCT FEATURES

// Open-Frame Power Supplies
// 200 W

Prices and delivery times are visible to registered and logged-in customers. New customers can request this information without obligation.

Sales only to business customers.
Delivery time: upon request

Basic Module: Fortron Source FSP200-PNA

General information
	SKU / Item Number			FSP200-PNA
Product Basic Data
	Manufacturer			Fortron Source
Power Supply
	Typ (Input)	AC	Range	90~264V
			Input frequency	47 to 63 Hz
	Power supply - Input			AC: 90~264V
	Output wattage			200 W
	Output Voltage	+12V	Output Current Max	16,6 A, -
		+24V	Output Current Max	8,33 A, -
		+48V	Output Current Max	4,17 A, -
	Efficiency	At 100% load / 25°C		90 %, 94 %
Mechanical / Environment
	Temperature	Operation		-20° down to 70°C
		Storage		-40°C to 85°C
	Relative humidity	Operation		10 to 95%, non-condensing
	Dimensions	Form factor		Open Frame (Housing)
		Width		199 mm
		Deep		99 mm
		Height		30 mm
	MTBF (Mean Time Between Failures)	MTBF at 25°C		300.000 h
		Calculation model		Telcordia SR-332
	Controls	Power (terminal connection)		1 Pce
Certificates / Conformities
	CE			Yes
	FCC	Class B		Yes
	Additional certificates / compliance approvals			EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2 (Electrostatic Discharge), EN 61000-4-3, EN 61000-4-4 (EFT), EN 61000-4-5 (2 kV Surge Protection), EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, IEC 62368-1
	RoHS compliant			Yes
