Serial Interface Cards
// M.2 Serial Interface Cards
Sales only to business customers.
Delivery time: upon request
Basic Module: Sunix M2S6437M
| General information | ||||
| SKU / Item Number | M2S6437M | |||
| Product Basic Data | ||||
| Manufacturer | Sunix | |||
| Extension | ||||
| M.2 | Slot 1 | Key ID | B + M | |
| Interface | PCIe ×1 (Gen. 2) | |||
| Supported dimensions | 2242, 2260, 2280 | |||
| M.2 Key IDs | B + M | |||
| Internal I/O | ||||
| Serial | RS-232 | 1.00 mm pitch | 2 Pce | |
| OS / Software | ||||
| Windows | Windows Server 2022 | is supported | ||
| Windows Embedded | Windows 10 Enterprise IoT LTSC (2021) | wind support | ||
| Windows 11 IoT | is supported | |||
| Linux | Distribution | Linux | ||
| Supported OS | Windows, Windows Embedded, Linux | |||
| Mechanical / Environment | ||||
| Temperature | Operation | 0°C to 70°C | ||
| Storage | -20° to 85°C | |||
| Relative humidity | Operation | 5 to 85%, non-condensing | ||
| Storage | 5 to 95%, non-condensing | |||
| Dimensions | Form factor | M.2 | ||
| Interface | PCI Express 1.0 x 1 | |||
| Width | 22 mm | |||
| Deep | 80 mm | |||
| Certificates / Conformities | ||||
| CE | Yes | |||
| FCC | Class A | Yes | ||
| Additional certificates / compliance approvals | BSMI, VCCI | |||
| RoHS compliant | Yes | |||
We are happy to advise you personally.
