14th Generation Intel Core i3/i5/i7/i9
// Intel Core i9-14901TE
// 5,50 GHz
// 36 MB Cache
// LGA 1700 (H6)
Sales only to business customers.
Delivery time: upon request
Basic Module: Intel i9-14901TE
| General information | ||||
| SKU / Item Number | i9-14901TE | |||
| Product Basic Data | ||||
| Manufacturer | Intel | |||
| Product ID | CM8071505103514 | |||
| System | ||||
| Processor | Vertical Segment | Embedded | ||
| Series | Intel Raptor Lake | |||
| Number | Intel Core i9-14901TE | |||
| CPU cores | 8 Pce | |||
| Threads | 16 Pce | |||
| Socket | LGA 1700 (H6) | |||
| Base frequency | 5,5 GHz | |||
| Max Turbo Frequency | 5,5 GHz | |||
| Performance core base clock frequency | 2,3 GHz | |||
| Cache | 36 MB | |||
| Thermal Design Power (TDP) | 45 W | |||
| Lithography | 10 nm | |||
| Spec Code | SRNJJ | |||
| Memory | Frequency | 5600 MHz | ||
| Maximum expansion | 192 GB | |||
| Graphics | ||||
| Processor | Intel UHD Graphics 770 | |||
| Performance feature | Support | DirectX 12, OpenCL 3.0, OpenGL 4.5 | ||
| Screens (Multi-display) | 4 displays | |||
| Extension | ||||
| PCI Express version | 5.0 | |||
| Max. PCI Express lanes | 20 Pce | |||
| Mechanical / Environment | ||||
| Temperature | Operation | 100°C | ||
| Dimensions | Width | 45 mm | ||
| Deep | 37,5 mm | |||
| Certificates / Conformities | ||||
| CE | Yes | |||
| RoHS compliant | Yes | |||
