4th Gen Intel Core i3/i5/i7
The product is EOL (End Of Life)!
// Intel Core i5-4400E
// 2,70 GHz
// 3 MB Cache
// BGA 1364
Sales only to business customers.
Delivery time: upon request
Basic Module: Intel i5-4400E
| General information | ||||
| SKU / Item Number | i5-4400E | |||
| Product Basic Data | ||||
| Manufacturer | Intel | |||
| Product ID | CL8064701483902 | |||
| System | ||||
| Processor | Vertical Segment | Embedded | ||
| Series | Intel Haswell | |||
| Number | Intel Core i5-4400E | |||
| CPU cores | 2 Pce | |||
| Threads | 4 Pce | |||
| Socket | BGA 1364 | |||
| Max. CPU-Bestückung | 1 Pce | |||
| Base frequency | 2,7 GHz | |||
| Max Turbo Frequency | 3,3 GHz | |||
| Cache | 3 MB | |||
| Bus Speed | 5 GT/s OPI | |||
| Thermal Design Power (TDP) | 37 W | |||
| Lithography | 22 nm | |||
| Spec Code | SR17M | |||
| Memory | Memory Type | DDR3 | ||
| Frequency | 1333 / 1600 MHz | |||
| Maximum expansion | 16 GB | |||
| ECC (Error-Correcting Code) | is supported | |||
| Intel vPro platform certification | Yes | |||
| Graphics | ||||
| Processor | Intel HD Grafics 4600 | |||
| Screens (Multi-display) | 3 displays | |||
| Extension | ||||
| PCI Express version | 3.0 | |||
| Max. PCI Express lanes | 16 Pce | |||
| Mechanical / Environment | ||||
| Temperature | Operation | 100°C | ||
| Dimensions | Form factor | Fixed (soldered) | ||
| Width | 32 mm | |||
| Deep | 37,5 mm | |||
| Height | 2 mm | |||
| Lifecycle | ||||
| Production start | Q3/2013 | |||
