Introducing the MX97N Thin Mini ITX Motherboard: Compact Power for Industrial Computing

BCM, USA, 21.11.2024 - BCM is thrilled to unveil the MX97N Thin Mini-ITX Motherboard, a cutting-edge solution engineered for industrial and embedded applications. Featuring Intel's N97 value-performance Processor, the MX97N delivers exceptional performance for entry level, making it an ideal choice for industries such as retail, HMI, and automation.

Key Features & Benefits

• Robust Performance: Equipped with Intel® Processor N97 and DDR5 memory support, the MX97N ensures reliable, high-speed computing for demanding applications.
• Compact and Cost-Effective: The MX97N's Thin Mini-ITX form factor with low-profile I/O offers robust performance in a compact, cost-efficient package.
• Enhanced Connectivity: Dual 2.5GbE LAN, multiple USB 3.2 Type C and Type A, HDMI, LVDS, dual DisplayPort, and 6 COM ports options, plus support for up to three independent 4K displays.
• Accelerated Time-to-Market: Compatible with the BI270 chassis, allowing for a complete, ready-to-deploy barebone system that reduces certification and development time.

Applications

The MX97N is suited for a wide range of applications, including:

• Retail Kiosks and POS Systems
• Healthcare Equipment and Remote Monitoring
• Digital Signage and Interactive Displays
• Industrial Automation and Smart Control Systems

Why Choose the MX97N?

The MX97N is purpose-built for space-constrained, high-performance environments where reliability and efficiency are key. Pairing with the BI270 chassis provides a turnkey, ready-to-go solution that helps you reach the market faster and with greater confidence. With its versatile connectivity, robust performance, and long lifecycle support, the MX97N is the optimal choice for next-generation embedded and industrial computing needs.

Hardware Features

• Intel® Processor N97, low power Quad-core Soc (12W TDP), Intel® Alder Lake N platform
• Low-profile design, Value-Packed Thin Mini ITX Motherboard
• Integrated Intel® UHD Graphic, supports 3 Independent Displays: 2 x DP 1.4a 4K, 1 x HDMI 1.4b, LVDS/eDP
• Dual 2.5GbE LAN: 2 x Intel® Ethernet Controller I226-V
• 1 x USB Type C
• 3 x USB 3.2 Gen2 Type A, 4 x USB 2.0
• 6 x COM/Serial Ports
• Expansion Slots: M.2 E-Key, M-Key, B-Key, PCIe x1 12V-24V Wide Range DC-In
• TPM 2.0
• Passive Cooling with Optional Cooling Fan
