New Open Frame Power Supply for Network Switch and PoE Switch Applications

FSP Group, Mönchengladbach, 06.08.2021 - Sailing in the trend of 5G smart applications, more and more construction, manufacturing companies are investing on infrastructure improvements. This further drives the demands of higher power and complex power systems. FSP Group had mapped out its Open Frame Power Supply product ranges ahead of the marketing demands. We are thrilled to introduce two new series, FSP260-P35 and FSP250-H24, to close the demand gap of middle-high wattage power requirements which are specifically made for but not limited to Network Switch and PoE Switch applications.

FSP260-P35 series have 4 single-output options including 12V, 18V, 24V or 54V. It supports 260W full output power in a dimension of 3'' x 5''. FSP250-H24 series, on the other hand, provides 250W full output power with a choice of 3 single-output models (12V, 24V or 54V) which come with a compact size in 2''x 4''. Foreseeing sustainability, efficiency, and reliability of power supply systems relying more on HVDC (High-Voltage Direct Current) technology, FSP’s team took HVDC input operation (128 ~370Vdc) into design feature. Both series maintain full power output at the fixed operating temperature of 50°C and 90-264Vac (128-370Vdc) without de-rating. At standby mode, the input power consumption is less than 0.5W.

Feature highlights

• Class-I design
• Input Voltage: FSP260-P35 90-264Vac, FSP250-H24 90-264Vac or HVDC 128-370V
• Output Wattage: FSP260-P35 260W @ Forced air cooling, 180W @ Convection cooling, FSP250-H24 250W@ Forced air cooling, 150W @ Convection cooling
• Low profile: FSP260-P35 3'' x 5'' , FSP250-H24 2'' x 4''
• Input power consumption < 0.5W @ 0.2W max load
• Surge protection ± 2 KV diff., ± 4 KV com
• High altitude 5000 meters operation
• Safety standard: IEC 62368-1
• Safety certificate: CB, UL, CE

Applications

• Network Switch
• PoE Switch
