Low-power Railway Gateway Computer with Intel Atom x6000E Processors

IBASE, Taipei, Taiwan, 29.09.2022 - IBASE Technology Inc. (TPEx: 8050), a world leading manufacturer of industrial motherboards and embedded computing solutions, is proud to announce its latest intelligent railway gateway computer supporting the new Intel® Atom® x6000E Series processors (codenamed Elkhart Lake). Certified with EU EN45545-2 fire protection and EN50155 standards covering equipment used on rolling stock applications such as Passenger Information System (PIS), surveillance systems and vehicle monitoring systems, the MPT-500R series is built to withstand up to 3Grms/3~500Hz vibration resistance and operating temperature of -30°C to +70°C.

The MPT-500R low-power, compact railway gateway system comes with 4GB/8GB LPDDR4 3200 memory on board, 64G MLC SSD storage with high reliability, and an option between 24V and 72/110V DC input to meet various power requirements. Featuring robust M12 USB, Ethernet and power input connectors, it ensures fail-safe connection and fault-free data transmission suitable for deployments in harsh industrial environments. It has two PoE ports that provide power to IP cameras and runs artificial intelligence identification. Measuring 210 x 138 x 96.8 mm (WxDxH), the unit supports a host of useful connectivity functions including HDMI, RS485, two SIM sockets with 4G/5G WWAN operation, 2280 M.2 M-key for PCI-E SSD and an mPCI-E full/half-size socket.

The rugged MPT-500R comes with a choice of Intel Atom x6212RE 1.2GHz or x6425RE 1.90GHz processor and runs with Windows 10, Windows 10 IoT Enterprise and Linux closed/open-source operating systems. Constructed with aluminum housing featuring passive cooling fins for long-term and stable operation, the model has received a Taiwan Excellence Award 2022 recognition.

MPT-500R FEATURES

• Intel® Atom® x6425RE/x6212RE processors
• EN50155 (2021) / EN45545-2 certified
• Fanless and ruggedized design
• Robust M12 connection for one 2.5G LAN, dual GbE LAN with PoE, dual USB
• Isolated USB, RS485 ports
• SIM socket with dual WWAN support
• Optional isolated CANbus thru Mini PCI-E card
• Wide-range operating temperature from -30°C to +70°C
