Wide-Temp MI836 Mini-ITX Motherboard for Reliable 24/7 Operation

IBASE, Taipei, Taiwan, 15.02.2023 - IBASE Technology Inc. (TPEx: 8050), a leading provider of embedded boards and solutions, has launched the MI836 industrial-grade Mini-ITX motherboard based on Intel® Atom® x6000E processor, with TDP ranges from 6W to 12W. It supports both passive and active thermal solutions with a wide operating temperature range from -20°C to 70°C, ensuring reliable operation even in outdoor and semi-outdoor environments.

The MI836 is practically suitable for various industries or applications that require the combination of performance and low-power design offered by the platform. These applications include real-time control systems, fleet monitoring and management systems, kiosks, and point-of-sale (POS) systems. It is equipped with 12V~24V DC input, two Intel® 2.5G Ethernet controllers, two DDR4 3200MHz slots with 32GB capacity and IBECC (In Band ECC) and graphics interface for HDMI (2.0b), VGA, and eDP or LVDS displays.

The MI836 provides a comprehensive set of I/O including 3x USB 3.1, 4x USB 2.0, 1x SATA III, 2x RS-232 COM, and 2x coastline RS-232/422/485 COM ports for secure serial communication over a network, and a variety of expansion slots, such as 1x PCIe Gen. 3, 1x mPCIe, 2x M.2 sockets (M-key and E-key) for add-on cards, storage devices and wireless connectivity. Supported operating systems include 64-bit Windows 10, Yocto, and Ubuntu.

MI836 FEATURES

• Onboard Intel® Atom® x6000 series processors
• 2x DDR4-3200 SO-DIMM sockets, Max. 32GB, supports IBECC
• Intel® Atom® processor integrated graphic HDMI (2.0b), VGA and LVDS or eDP
• Dual Intel® 2.5G LAN (I226IT)
• 3x USB 3.1, 4x USB 2.0, 4x COM, 1x SATA III
• 1x PCIe (x1) [Gen. 3.0], 1x mPCIe, 2x M.2 sockets (M-key & E-key)
• Watchdog timer, Digital I/O, fTPM
• Wide-range operating temperature from -20°C to +70°C
