Embedded System
// Embedded System
// [Intel Celeron N3450 | Intel Pentium N4200]
// 1,1 GHz
// Passiv gekühlt
// 2 x Anzeige
// 1 x Seriell
// 2 x USB (Frontseite)
// 2 x USB (Rückseite)
// 2 x G-LAN (Rückseite)
// 1 x Mini-PCIe
// 2 x M.2 Slot
// 12V / 19V (Autoswitch)
Bitte konfigurieren Sie Ihr Wunschprodukt.
Standardkonfiguration
Individualkonfiguration
Verkauf nur an gewerbliche Kunden.
Lieferzeit: auf Anfrage
Basismodul: GIGAIPC GB-EA
Allgemein | ||||
SKU / Artikelnummer | GB-EA | |||
Produktgrunddaten | ||||
Hersteller | GIGAIPC | |||
System | ||||
Prozessor | Serie | Intel Apollo Lake | ||
Nummer | Intel Celeron N3450, Intel Pentium N4200 | |||
CPU Kerne | 4 St | |||
Threads | 4 St | |||
Sockel | BGA 1296 | |||
Basis Frequenz | 1,1 GHz | |||
Cache | 2 MB | |||
Thermal Design Power (TDP) | 6 W | |||
Speicher | Aufbau | 204 Pin SO-DIMM DDR3L | ||
Frequenz | 1600 / 1866 MHz | |||
Steckplätze | 2 St | |||
Maximaler Ausbau | 8 GB | |||
Grafik | ||||
Prozessor | Intel HD Graphics 500, Intel HD Graphics 505 | |||
HDMI | Maximale Auflösung | 3840 x 2160 bei 30 Hz | ||
Version | 1.4 | |||
Erweiterung | ||||
Mini-PCIe | Halbe Bautiefe | Anzahl | 1 St | |
PCIe Schnittstellen | 1x Mini-PCIe | |||
M.2 | Slot 1 | Interface | SATA III | |
Unterstütze Abmaße | 2280 | |||
Slot 2 | Interface | Bluetooth, WLAN | ||
Unterstütze Abmaße | 2230 | |||
SIM | PCIe / USB 2.0 Unterstützung | 1 St | ||
Storage | Micro-SD | |||
Audio | ||||
Chipsatz | Realtek ALC255 | |||
Netzwerk | ||||
G-LAN | Controller | Chipsatz | Realtek RTL8111HS (10/100/1000 Mbps) | |
Anzahl | 2 St | |||
Wireless | Wi-Fi | Protokoll | 802.11 ac | |
Netzwerk | 2x G-LAN, Wi-Fi | |||
Externe I/O (Frontseite) | ||||
Seriell | RS-232 / 422 / 485 | RJ-45 | 1 St | |
USB | USB v3.0 | 2 St | ||
Externe I/O (Rückseite) | ||||
Anzeige | HDMI | 2 St | ||
Audio | Line-Out | 1 St | ||
Mic-In | 1 St | |||
Ethernet | RJ-45 | 2 St | ||
USB | USB v3.0 | 2 St | ||
Sicherheit | ||||
Trusted Platform Modul (TPM) | Auf Anfrage | |||
Stromversorgung | ||||
Typ (Eingang) | DC | Bereich | 12V / 19V (Autoswitch) | |
Anschluss | Hohlstecker | |||
Stromversorgung - Eingang | DC: 12V / 19V (Autoswitch) | |||
Kühlung | ||||
Umsetzung | Passiv | |||
Mechanik / Umgebung | ||||
Temperatur | Betrieb | 0° bis 50°C | ||
Lagerung | -20° bis 60°C | |||
Abmaße | Formfaktor | Embedded System | ||
Breite | 105 mm | |||
Tiefe | 165 mm | |||
Höhe | 27 mm | |||
Gewicht | 738 g | |||
Bedienelemente | Power | 1 St | ||
Antennenlöcher | 3 St | |||
Montageoption | VESA | |||
Betriebssysteme / Software | ||||
Windows | Windows 10 (64-bit) | wird unterstützt | ||
Unterstützte BS | Windows |
