Embedded System
// Embedded System
// [Intel Core Ultra 5 Prozessor 135H | Intel Core Ultra 7 Prozessor 165H]
// Aktiv (Lüfterkühlung) gekühlt
// 2 x Anzeige
// 1 x Seriell
// 4 x USB (Frontseite)
// 2 x G-LAN (Frontseite)
// 3 x M.2 Slot
// 24V
Bitte konfigurieren Sie Ihr Wunschprodukt.
Standardkonfiguration
Individualkonfiguration
Verkauf nur an gewerbliche Kunden.
Lieferzeit: auf Anfrage
Basismodul: IBASE ASB210-962H
Allgemein | ||||
SKU / Artikelnummer | ASB210-962H | |||
Produktgrunddaten | ||||
Hersteller | IBASE | |||
System | ||||
Prozessor | Vertikales Segment | Mobile | ||
Serie | Intel Meteor Lake | |||
Nummer | Intel Core Ultra 5 Prozessor 135H, Intel Core Ultra 7 Prozessor 165H | |||
CPU Kerne | 14 St, 16 St | |||
Threads | 18 St, 22 St | |||
Sockel | BGA 2049 | |||
Performance-core Grundtaktfrequenz | 1,4 GHz, 1,7 GHz | |||
Performance-core Max Turbo Frequenz | 4,6 GHz, 5 GHz | |||
Efficient-core Grundtaktfrequenz | 0,9 GHz, 1,2 GHz | |||
Efficient-core Max Turbo Frequenz | 3,6 GHz, 3,8 GHz | |||
Cache | 18 MB, 24 MB | |||
Grundleistungsaufnahme des Prozessors | 28 W | |||
Maximale Turbo-Leistungsaufnahme | 115 W | |||
Chipsatz | SoC (System-On-Chip) | |||
Speicher | Aufbau | 262 Pin SO-DIMM DDR5 | ||
DIMM Type | Unbuffered SO-DIMM | |||
Frequenz | 5600 MHz | |||
Steckplätze | 2 St | |||
Maximaler Ausbau | 64 GB | |||
Grafik | ||||
Prozessor | Intel Arc Graphics | |||
Erweiterung | ||||
M.2 | Slot 1 | Key ID | B | |
Interface | 5G / Storage Module | |||
Unterstütze Abmaße | 3052 | |||
Slot 2 | Key ID | E | ||
Unterstütze Abmaße | 2230 | |||
Slot 3 | Key ID | M | ||
Interface | NVMe | |||
Unterstütze Abmaße | 2280 | |||
M.2 Key IDs | B, E, M | |||
SIM | Anzahl | 1 St | ||
Formfaktor (Slot) | Micro SIM | |||
Storage | M.2 | |||
Interne I/O | ||||
Serial-ATA | S-ATA R3.0 (6 Gbit/s, 600 MB/s) | 1 St | ||
Externe I/O (Frontseite) | ||||
Anzeige | HDMI | 1 St | ||
Displayport | 1 St | |||
Ethernet | RJ-45 | 2 St | ||
Seriell | RS-232 / 422 / 485 | DB-9 | 1 St | |
USB | USB v2.0 | 1 St | ||
USB v3.2 (Gen 1) | 3 St | |||
Externe I/O (Rückseite) | ||||
Digital I/O | Anzahl | 1 St | ||
Bits | 8-Bit | |||
Anschluss | 10 Pin Terminal Stecker | |||
Stromversorgung | ||||
Typ (Eingang) | DC | Weitbereich | Nein | |
Bereich | 24V | |||
Anschluss | 3 Pin Terminal Stecker | |||
Stromversorgung - Eingang | DC: 24V | |||
Kühlung | ||||
Umsetzung | Aktiv (Lüfterkühlung) | |||
Aktiv | Lüfter | Anzahl | 1 St | |
Mechanik / Umgebung | ||||
Temperatur | Betrieb | -10° bis 45°C | ||
Lagerung | -20° bis 80°C | |||
Relative Luftfeuchtigkeit | Betrieb | 5 bis 90%, nicht kondensierend | ||
Abmaße | Formfaktor | Embedded System | ||
Breite | 180 mm | |||
Tiefe | 150 mm | |||
Höhe | 72 mm | |||
Vibration | Vibration | 1G, 5~500 Hz | ||
Schock | Messdaten | 20G, 11 ms | ||
Gewicht | 1600 g | |||
Bedienelemente | Power | 1 St | ||
Statusanzeigen | Storage | 1 St | ||
Power | 1 St | |||
Antennenlöcher | 4 St | |||
Farbe | Schwarz | |||
Material | Aluminium, Stahl | |||
Montageoption | VESA, Wandmontage | |||
Betriebssysteme / Software | ||||
Windows | Windows 11 | Wird unterstützt | ||
Unterstützte BS | Windows | |||
Zertifikate / Konformitäten | ||||
CE | Ja | |||
FCC | Class B | Ja | ||
Weitere Zertifikate / Konformitäten | LVD | |||
RoHS konform | Ja |
