Fahrzeug (In-Vehicle) System
// Fahrzeug (In-Vehicle) System
// [- | Intel Core i7-10700TE]
// [2 | -] GHz
// Passiv gekühlt
// 6 x Anzeige
// 5 x Seriell
// 4 x USB (Frontseite)
// 4 x USB (Rückseite)
// [4 | 6] x G-LAN (Frontseite)
// 1 x Mini-PCIe
// 3 x M.2 Slot
// 9~48V
Bitte konfigurieren Sie Ihr Wunschprodukt.
Standardkonfiguration
Individualkonfiguration
Verkauf nur an gewerbliche Kunden.
Lieferzeit: auf Anfrage
Basismodul: DFI VC500-CMS-MXM
Allgemein | ||||
SKU / Artikelnummer | VC500-CMS-MXM | |||
Produktgrunddaten | ||||
Hersteller | DFI | |||
Produkt-ID | 750-VC50000-400G, 750-VC50000-500G, 750-VC50000-510G | |||
System | ||||
Prozessor | Vertikales Segment | Embedded | ||
Serie | Intel Comet Lake | |||
Nummer | -, Intel Core i7-10700TE | |||
CPU Kerne | 8 St, - | |||
Threads | 16 St, - | |||
Sockel | LGA 1200 (H5) | |||
Basis Frequenz | 2 GHz, - | |||
Max. Turbo-Taktfrequenz | 4,4 GHz, - | |||
Cache | 16 MB, - | |||
Thermal Design Power (TDP) | 35 W | |||
Lithographie | 14 nm | |||
Chipsatz | Intel Q470E | |||
Speicher | Aufbau | 260 Pin SO-DIMM DDR4 | ||
Memory Type | DDR4 | |||
Frequenz | 2666 / 2933 MHz | |||
Steckplätze | 2 St | |||
Maximaler Ausbau | 64 GB | |||
ECC | wird nicht unterstützt | |||
BIOS | AMI SPI 256 Mbit | |||
Grafik | ||||
Prozessor | -, Nvidia RTX A1000 | |||
Erweiterung | ||||
Mini-PCIe | Volle Bautiefe | Anzahl | 1 St | |
PCIe Schnittstellen | 1x Mini-PCIe | |||
M.2 | Slot 1 | Key ID | E | |
Interface | PCIe ×1 (Gen. 3), USB 2.0 | |||
Unterstütze Abmaße | 2230 | |||
Slot 2 | Key ID | B | ||
Interface | 4G/LTE, 5G / Storage Module | |||
Unterstütze Abmaße | 3042, 3052 | |||
Slot 3 | Key ID | M | ||
Unterstütze Abmaße | 2242, 2280 | |||
M.2 Key IDs | B, E, M | |||
Mobile PCI Express Module (MXM) | wird unterstützt | |||
Audio | ||||
Chipsatz | Realtek ALC888 | |||
Netzwerk | ||||
G-LAN | Controller | Chipsatz | Intel I219 PCIe (10/100/1000 Mbps) | |
Anzahl | 1 St | |||
Controller | Chipsatz | Intel I210IT PCIe (10/100/1000 Mbps) | ||
Anzahl | 1 St | |||
Controller | Chipsatz | -, Intel X710-BM2 (1/10 Gbps) | ||
Anzahl | 1 St, - | |||
Netzwerk | 2x G-LAN, 3x G-LAN | |||
Interne I/O | ||||
Seriell | RS-232 | Ports (2.54 mm Pitch) | 1 St | |
Serial-ATA | S-ATA R3.0 (6 Gbit/s, 600 MB/s) | 2 St | ||
Raid Unterstützung | RAID 0/1 | wird unterstützt | ||
RAID Unterstützung | RAID 0/1 | |||
Externe I/O (Frontseite) | ||||
Anzeige | Displayport | 4 St | ||
Audio | Line-In | 1 St | ||
Line-Out | 1 St | |||
Mic-In | 1 St | |||
Ethernet | RJ-45 | 2 St | ||
RJ-45 mit POE | 4 St, - | |||
SFP+ (enhanced small form-factor pluggable) | 2 St, - | |||
Seriell | RS-232 | DB-9 | 1 St | |
Digital I/O | Anzahl | 2 St | ||
Bits | 8-Bit | |||
Anschluss | DB-15 | |||
USB | USB v3.1 Gen. 2 | 4 St | ||
Externe I/O (Rückseite) | ||||
Anzeige | DP++ | 2 St | ||
DP++ / HDMI Dual Connector | 1 St | |||
Seriell | RS-232 / 422 / 485 | DB-9 | 4 St | |
USB | USB v3.1 Gen. 2 | 4 St | ||
SIM | Anzahl | 3 St | ||
Formfaktor (Slot) | Micro SIM | |||
Sensor | ||||
3D Sensor | 3D Accelerometer | |||
Sicherheit | ||||
Trusted Platform Modul (TPM) | dTPM 2.0 (Hardware) | |||
Stromversorgung | ||||
Typ (Eingang) | DC | Weitbereich | Ja | |
Bereich | 9~48V | |||
Anschluss | 3 Pin 3W3 Anschluss | |||
Ignition (IGN) | Ja | |||
POE | Anschlüsse | 4 St, - | ||
Protokoll | -, IEEE 802.3af / 15.4W | |||
Stromversorgung - Eingang | DC: 9~48V | |||
Kühlung | ||||
Umsetzung | Passiv | |||
Passiv | Wärmemanagement | Wärmespreizer (Heat Spreader) | ||
Einschübe | ||||
Extern | Einbauschacht 2.5" | 2 St | ||
Mechanik / Umgebung | ||||
Temperatur | Betrieb | -20° bis 60°C | ||
Lagerung | -40° bis 85°C | |||
Relative Luftfeuchtigkeit | Betrieb | 10 bis 95%, nicht kondensierend | ||
Abmaße | Formfaktor | Fahrzeug (In-Vehicle) System | ||
Breite | 346 mm | |||
Tiefe | 221 mm | |||
Höhe | 87,55 mm | |||
Vibration | Referenz Standard | MIL-STD-810G Method 514.6 | ||
Schock | Messdaten | 10G, halben Sinusschwingung, 11 ms Dauer | ||
Referenz Standard | MIL-STD-810G Method 516.6 Procedure I | |||
Gewicht | 6950 g | |||
Bedienelemente | Power | 1 St | ||
Power (Terminal Anschluss) | 1 St | |||
Reset | 1 St | |||
Statusanzeigen | Storage | 1 St | ||
Power | 1 St | |||
System Status | 2 St | |||
Antennenlöcher | 8 St | |||
Farbe | Schwarz / Silber | |||
Material | Aluminium, Stahl | |||
Montageoption | Wandmontage | |||
Betriebssysteme / Software | ||||
Windows Embedded | Windows 10 Enterprise IoT LTSC (2019) | wird unterstützt | ||
Windows 11 IoT | wird unterstützt | |||
Linux | Distribution | Ubuntu 20.04 | ||
Unterstützte BS | Linux, Windows Embedded | |||
Zertifikate / Konformitäten | ||||
CE | Ja | |||
FCC | Class A | Ja | ||
Weitere Zertifikate / Konformitäten | E-Mark | |||
RoHS konform | Ja |
