Network Appliance System
// Network Appliance System
// [- | Intel Xeon E-2378 | Intel Xeon E-2378G]
// [2,6 | 2,8 | -] GHz
// Aktiv (Lüfterkühlung) gekühlt
// 2 x USB (Frontseite)
// 2 x USB (intern)
// 8 x G-LAN (Frontseite)
// 1 x PCIe x4
// 1 x PCIe x8
// 1 x Mini-PCIe
// 1 x M.2 Slot
Bitte konfigurieren Sie Ihr Wunschprodukt.
Standardkonfiguration
Individualkonfiguration
Verkauf nur an gewerbliche Kunden.
Lieferzeit: auf Anfrage
Basismodul: IEI PUZZLE-5030
Allgemein | ||||
SKU / Artikelnummer | PUZZLE-5030 | |||
Produktgrunddaten | ||||
Hersteller | IEI | |||
System | ||||
Prozessor | Vertikales Segment | Server | ||
Serie | Intel Rocket Lake | |||
Nummer | -, Intel Xeon E-2378, Intel Xeon E-2378G | |||
CPU Kerne | 8 St, - | |||
Threads | 16 St, - | |||
Sockel | LGA 1200 (H5) | |||
Basis Frequenz | 2,6 GHz, 2,8 GHz, - | |||
Max. Turbo-Taktfrequenz | 4,8 GHz, 5,1 GHz, - | |||
Cache | 16 MB, - | |||
Thermal Design Power (TDP) | 65 W, 80 W, - | |||
Chipsatz | Intel C256 | |||
Speicher | Aufbau | 288 Pin DIMM DDR4 | ||
Memory Type | DDR4 | |||
DIMM Type | Unbuffered DIMM | |||
Frequenz | 3200 MHz | |||
Steckplätze | 4 St | |||
Maximaler Ausbau | 128 GB | |||
ECC | wird unterstützt | |||
Grafik | ||||
Prozessor | -, Intel UHD Graphics | |||
Erweiterung | ||||
PCIe x4 | Generation | 4 | ||
x4 Signal | 1 St | |||
PCIe x8 | Generation | 4 | ||
x8 Signal | 1 St | |||
Mini-PCIe | Volle Bautiefe | Anzahl | 1 St | |
PCIe Schnittstellen | 1x Mini-PCIe, 1x PCIe x4, 1x PCIe x8 | |||
M.2 | Slot 1 | Key ID | M | |
Interface | PCIe ×2 (Gen. 4), SATA III | |||
Unterstütze Abmaße | 2260, 2280 | |||
M.2 Key IDs | M | |||
NIC Module Slot | Anzahl | 2 St | ||
SIM | Anzahl | 1 St | ||
Formfaktor (Slot) | Micro SIM | |||
Storage | M.2 | |||
Netzwerk | ||||
G-LAN | Controller | Chipsatz | Intel I225V PCIe (10/100/1000/2500 Mbps) | |
Anzahl | 8 St | |||
Bypass | Ja | |||
Netzwerk | 8x G-LAN | |||
Interne I/O | ||||
USB | USB v2.0 | Ports (2.54 mm Pitch) | 2 St | |
Anzeige | HDMI (Golden Finger) | 1 St | ||
Serial-ATA | S-ATA R3.0 (6 Gbit/s, 600 MB/s) | 2 St | ||
Externe I/O (Frontseite) | ||||
Anzeige | LCM Display | 2 x 16 Zeichen | ||
Ethernet | RJ-45 | 8 St | ||
USB | USB v3.0 | 2 St | ||
Console | RJ45 Anschluss | |||
Sicherheit | ||||
Trusted Platform Modul (TPM) | TPM header | |||
Stromversorgung | ||||
Typ (Eingang) | AC | Bereich | 100~240V | |
Einschübe | 2 St | |||
Anschluss | C19 | |||
Stromversorgung - Eingang | AC: 100~240V | |||
Stromaufnahme Maximal | 300 W | |||
Kühlung | ||||
Umsetzung | Aktiv (Lüfterkühlung) | |||
Aktiv | Lüfter | Anzahl | 3 St | |
Lüfter | Anzahl | 1 St | ||
Einschübe | ||||
Intern | Einbauschacht 2.5" | 2 St | ||
Mechanik / Umgebung | ||||
Temperatur | Betrieb | 0° bis 40°C | ||
Lagerung | -10° bis 50°C | |||
Relative Luftfeuchtigkeit | Betrieb | 5 bis 90%, nicht kondensierend | ||
Abmaße | Formfaktor | Network Appliance System | ||
Breite | 430 mm | |||
Tiefe | 426 mm | |||
Höhe | 44,2 mm | |||
Höheneinheiten | 1 HE | |||
Gewicht | 10000 g | |||
Bedienelemente | Power | 1 St | ||
Reset | 1 St | |||
Statusanzeigen | Storage | 1 St | ||
Power | 1 St | |||
System Status | 1 St | |||
Slot Brackets | Standard | 2 St | ||
Antennenlöcher | 1 St | |||
Betriebssysteme / Software | ||||
Linux | Distribution | Linux | ||
Unterstützte BS | Linux | |||
Zertifikate / Konformitäten | ||||
CE | Ja | |||
FCC | Class A | Ja | ||
RoHS konform | Ja |
