Rugged Tablets
Produkt ist EOL (End Of Life)!
// 12,2" TFT-LCD
// BGA 1356
// Touchscreen (Kapazitiv)
// IP65 (komplett)
// 8 GB
// 1 x G-LAN (Back side)
// 1 x USB (Back side)
Verkauf nur an gewerbliche Kunden.
Lieferzeit: auf Anfrage
Basismodul: MSI NF21
Allgemein | ||||
SKU / Artikelnummer | NF21 | |||
Produktgrunddaten | ||||
Hersteller | MSI | |||
System | ||||
Prozessor | Serie | Intel Kaby Lake | ||
CPU Kerne | 2 St | |||
Threads | 4 St | |||
Sockel | BGA 1356 | |||
Thermal Design Power (TDP) | 15 W | |||
Speicher | Memory Type | DDR4 | ||
Speicher onBoard | 8 GB | |||
Display | ||||
Display Type | 12,2" TFT-LCD | |||
Max. Auflösung | 1920 x 1200 | |||
Seitenverhältnis | 8 : 5 | |||
Leuchtdichte | 800 cd/m² | |||
Touchscreen | Typ | Kapazitiv | ||
Multitouch | 10-Punkt | |||
Erweiterung | ||||
SIM | PCIe / USB 2.0 Unterstützung | 1 St | ||
Netzwerk | ||||
Wireless | Wi-Fi | Wi-Fi Standards (IEEE 802.11) | 802.11a/b/g/n/ac | |
Bluetooth | Versions / Features | v4.2 | ||
Netzwerk | Wi-Fi, Bluetooth | |||
Externe I/O (Rückseite) | ||||
Anzeige | Micro HDMI | 1 St | ||
Audio | Line-Out | 1 St | ||
Mic-In | 1 St | |||
Ethernet | RJ-45 | 1 St | ||
USB | USB v3.0 | 1 St | ||
Sensor | ||||
3D Sensor | 3D Accelerometer, 3D Gyroscope | |||
E-Compass | Ja | |||
Lichtsensor | Ja | |||
Sicherheit | ||||
Trusted Platform Modul (TPM) | v2.0 | |||
Mechanik / Umgebung | ||||
Temperatur | Betrieb | -10° bis 50°C | ||
Abmaße | Formfaktor | 12,2" | ||
Breite | 214 mm | |||
Tiefe | 318 mm | |||
Höhe | 27 mm | |||
Schutzart (IP) | IP65 (komplett) | |||
Vibration | Referenz Standard | MIL-STD-810G | ||
Schock | Referenz Standard | MIL-STD-810G | ||
Gewicht | 1800 g | |||
Bedienelemente | Power | 1 St | ||
Reset | 1 St | |||
Betriebssysteme / Software | ||||
Windows Embedded | Windows 10 Enterprise IoT LTSB (2016) | wird unterstützt | ||
Unterstützte BS | Windows Embedded |
